OEM High Quality Medical X Ray Tube Factories - Medical X-ray Collimator Manual X-ray Collimator SR102 – Sailray Detail:

X-ray leakage: <1mGy/h (150kV, 4mA)
The distance from the focus of the X-ray tube to the beam limiter mounting surface: 60mm (can be adjusted according to different tubes)
Light field consistency: <2%@SID
Inherent filtration: 1mmAl/75kV

Optional:
External additional filter
Special electrical interface
Special tube ball interface

Max Voltage

150KV

Maximum X-ray field  coverage  range

440mmx440mm (SID=100cm)

The average brightness of the light field

>160 lux

Edge contrast ratio

>4:1

Power supply requirement of projection lamp

24V/100W

Bright  X-ray  field  duration  for  Once

30S

Distance from Focal Spot of X-ray tube to the mount plane of collimator  SID  (mm)(optional)

60

Filtration(Inherent) 75kV

1mmAl

Filtration(Additional)

The outer optional

Control  method

Manual

Drive motor

Motor Control

Position detection

Input power

AC24V

(SID)Measuring tape

Standard Configuration

Center laser instructions

Dimension(mm)(W×L×H)

223x185x87

Weight(Kg)

5.5

This x-ray collimator is suitable for common X-ray diagnostic equipment with a tube voltage of 150kV, DR.


Product detail pictures:

OEM High Quality Medical X Ray Tube Factories - Medical X-ray Collimator Manual X-ray Collimator  SR102 – Sailray detail pictures

OEM High Quality Medical X Ray Tube Factories - Medical X-ray Collimator Manual X-ray Collimator  SR102 – Sailray detail pictures

OEM High Quality Medical X Ray Tube Factories - Medical X-ray Collimator Manual X-ray Collimator  SR102 – Sailray detail pictures

OEM High Quality Medical X Ray Tube Factories - Medical X-ray Collimator Manual X-ray Collimator  SR102 – Sailray detail pictures
